Stiebel Eltron 223425 Tempra 29 Plus Whole House Tankless Electric Water Heater 21 6 28 8 Kw 0 87 Gpm

The Stiebel Eltron Tempra 29 Plus Tankless Water Heater features exclusive Advanced Flow Control German patented technology invented by Stiebel Eltron to automatically maintain water temperature for constant comfort. It’ll reduce flow slightly if hot water demand exceeds capacity to ensure that hot showers will never be interrupted. Although, it’s possible to save significantly more energy depending on personal home usage habits. The difference is that conventional tank water heaters continually store hot water, and as a result, lose 15%-20% of the total energy consumed to the environment around them. This is called standby heat loss. Our tankless water heaters do not need venting, and will not store hot water, waiting for you to use it. CERTIFICATIONS INCLUDE - ANSI/UL Std. 499, CSA Std. C22.2 No. 88, ISO 9001, WQA tested & certified against NSF/ANSI 372 for lead free compliance. TECHNICAL SPECIFICATIONS – Single Phase 50/60 Hz; Voltage: 240 V/208 V; Wattage: 28.8 KW/21.6 KW; Min. recommended household electric service 200 A; Amperage draw: 3 x 40 A 3 x 35 A; Number and min. recommended size of circuit breakers: 3 x 35 A (DP); Number of runs and min. inlet water temperature: 131 F/55 C; Working pressure: 150 PSI/10 BAR; Tested to pressure: 300 PSI / 20 BAR; Water connections: 3/4 NPT. On demand a continuous and unlimited supply of hot water Requires hard-wired 240 or 208-volt electric service, with a maximum draw of 28,800 watts at 240 volts or 21,600 watts at 208 volts Requires 3 separate dedicated 40 amp breakers with 8 gauge copper wiring, and a minimum of 200 amp total service to the residence
